Chapter Quick Navigation:
948cc & 1098cc Brake & Clutch Pedal Box Assembly - Chapter 9 Pages 4-5
Sprite Catalog Page 9-5
Records - of

No.

Part No

Description

Qty

Remarks

AHA6407  BRAKE PEDAL  1
AHA6408  CLUTCH PEDAL  1 NOT ILLUSTRATED
2A5564  *NLA*BRK & CLTCH BUSH  2
2A5568  BOLT PEDAL PIVOT  1
GHF332  LOCKWASHER 5/16 IN VARIOUS  1 5/16"
GHF201  5/16 PLAIN NUT  1 5/16"
2A5575  PIN CLEVIS PEDAL-MSTR  2
2A5576  FORK PEDAL M/C 58-66  2
1B3498  CLIP RETAINING  2
AHA6409  ROD ACTUATING M/C >66  2
10  NT605041  JAMNUT TR2-4A & AH & SPM  2 5/16"
11  2A5574  SPRING PEDAL RETURN  2
12  AHA6366  PEDAL BOX APERTURE SEAL  2
13  2A5572  SEAL BRAKE/CLUTCH PED  1
14  AHA5326  PAD BRAKE & CLUTCH  2
15  GHF101  SET SCREW  2 1/4"
16  NT604041  JAM NUT undefined  4 1/4"
17  SH604051  SCREW  9 1/4"
17  GHF101  SET SCREW LONG  1 1/4 NOT ILLUSTRATED
17  SH604051  BLANKING PLATE SCREW  8 1/4" NOT ILLUSTRATED
18  GHF331  LOCKWASHER 1/4" ID SQUARE SECTION VARIOUS  18 1/4"
19  39121  MASTER CYLINDER DUAL SPRIDGET TO 1966 BRAKE & CLUTCH  1 948cc/DRUM BRAKES GMC109
19  422-804  3/4" MASTER CYLINDER ASSEMBLY  1 1098cc/DISC BRAKES GNC112
20  SSB717  BRAKE MASTER CYLINDER KIT 3/4" BORE FOR 63-66 SPRITE & MIDGE  1 1098cc/DISC BRAKES
20  KL71527  KIT M/C 58-63 SPRITE  1 948cc/DRUM BRAKES
21  17H3723  METAL FILLER CAP  1 ALTERNATIVE
22  513123  PLASTIC FILLER CAP  1
23  37H2496  GASKET TOP M/C 58-66  1
24  AAA4757  GASKET SIDE M/C 58-66  1
25  AAA4758  SCREW MASTER CYL LID  7 1/4"
26  GHF321  LOCK WASHER undefined  7 1/4"
27  AJH5083  SPRING H26 undefined  2
28  BH606241  SHORT MOUNTING BOLT  1 3/8"
28  BH606261  BOLT RR SPRING;1/4 EL  1 3/8" NOT ILLUSTRATED
29  GHF333  LOCKWASHER 3/8 IN undefined  2 3/8"
30  GHF202  NUT VARIOUS  2 3/8"
31  2A5573  SPRING RETAINER  2
